NEC EA242F

24" LCD monitor with LED backlight, 1920x1080, USB-C, DisplayPort, HDMI, USB 3.1, 150 mm height adjustable Product Information Product Name MultiSync® EA242F Product Group LCD 23.8" Enterprise Display Order Code 60005246 (WH), 60005032 (BK) Display Panel Technology IPS TFT with W-LED backlight Screen Size [inch/cm] 24 / 60.47 Screen Aspect Ratio 16:9 Colour Gamuts 101.6 % sRGB; 75.3% AdobeRGB, 72% NTSC Pixel Pitch [mm] 0.275 Brightness (typ.) [cd/m2] 250 Contrast Ratio (typ.) 1000:1 (5000:1 dynamic contrast ratio) Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1) Response Time (typ.) [ms] 5 (grey-to-grey) Colours [Mio.] 16.78 (6-bit per colour) Synchronisation Rate Horizontal Frequency [kHz] 31.5 - 83 Vertical Frequency [Hz] 50 - 75 Resolution Optimum Resolution 1920 x 1080 at 60 Hz Supported 1920 x 1080; 1680 x 1050; 1440 x 900; 1280 x 1024; 1280 x 960; 1280 x 720; 1024 x 768; 800 x 600; 720 x 576; 720 x 480; 720 x 400; 640 x 480 Connectivity Digital 1 x DisplayPort; 1 x DisplayPort out; 1 x HDMI; 1 x USB Type C; USB ver. 3.1 (3 down / 1 up) Analog 1 x D-sub 15 pin Electrical Power Consumption on Mode [W] 15 (Eco Mode 2); 21 (typ.) Power Savings Mode [W] 0.3 Power Supply 0.9 A/0.5 A; 100-240 V; internal power supply Environmental Conditions Operating Temperature [°C] +5 to +35 Operating Humidity [%] 20 to 80 Storage Humidity [%] 10 to 85 Storage Temperature [°C] -10 to 60 Ergonomics Height adjustable stand [mm] 150 (Landscape mode) Screen Tilt [°] -5 to 35 Screen Swivel [°] -170 to 170 Screen Rotate [°] 0 to 90 (landscape to portrait mode) LCD 23.8 Enterprise Display - MultiSync® EA242F (2 / 3) Mechanical Bezel Width [mm] 0.8 (left/right/top); 15.8 (bottom) Dimensions (W x H x D) [mm] 319.1 x 555.6 - 615.4 x 250 (Portrait mode); 537.7 x 336.6 - 486.6 x 250 (Landscape mode) Weight [kg] With stand: 7 VESA Mounting [mm] 100 x 100 (4 points) Additional Features Colour Versions Black Front Bezel, Black Back Cabinet Cable Management yes Kensington security slot yes Plug and Play DDC2B/2Bi; VESA DDC/CI; VESA DDC2Bi Audio Integrated Speakers (1 W + 1 W) Adjust Functions Advanced NTAA (Advanced Non-Touch-Auto-Adjustment) Shipping Content Control Sync Cable; DisplayPort cable; Monitor; Power Cable; Set-up Manual; USB Cable; USBC Cable Safety and Ergonomics CE; EAC; EnergyStar 8.0; ErP; Flicker-free; ISO 9241-307 (pixel failure class I); PSB; RoHS; TCO 8.0; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA; WEEE Warranty 3 years warranty incl. backlight; optional 1st to 3rd year 24/7 usage warranty; optional 4th to 5th year warranty extension Green Features Energy Efficiency Ambient light sensor; Energy efficiency class: A+; Human sensor Ecological Standards ErP compliant; RoHS compliant; WEEE.
